1130 Tedea Load Cell

1130 Tedea Load Cell Specification

Color
White

Usage
Industrial

Material
Alloy Steel

Application
Platform Scale

Capacity
50kg to 200kg Kg

Type
Load Cell

1130 Tedea Load Cell Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
30 Units Per Month

Delivery Time
2-7 Days

Main Domestic Market
All India

About 1130 Tedea Load Cell

The 1130 Tedea Load Cell is made of high-quality alloy steel, making it durable and reliable for industrial applications. With a capacity range of 50kg to 200kg, this load cell is suitable for use in platform scales. The load cell is white in color and hermetically sealed, ensuring protection against moisture and dust. It is certified by OIML and has an IP68 rating for dust and water resistance. The output sensitivity is 3.0 +/- 0.003 mV/V, and it has an accuracy class of OIML R60 C3. The load cell has a maximum safe overload of 150% FS and an ultimate safe overload of 200% FS. It operates on a recommended excitation voltage of 5 to 15V DC and has an insulation resistance of >= 5000 M Ohm. The compensated and operating temperature range is -10 to +40 Deg C, making it suitable for a variety of environments.

Model	1130
Ingress Protection	IP68
Application	Platform Scale
Features	Hermetically Sealed
Load Cell Certifications	OIML
Output Sensitivity(FS)	3.0 +/- 0.003 mV/V
Accuracy Class	OIML R60 C3
Maximum Safe Overload	150% FS
Ultimate Safe Overload	200% FS
Recommended Excitation Voltage	5 to 15V DC
Maximum Excitation Voltage	15V DC
Insulation resistance at 50V DC	>= 5000 M Ohm
Compensated Temperature Range	-10 to +40 Deg C
Operating Temperatue Range	-10 to +40 Deg C
